Inverter Welding Machine GM2000

Inverter Welding Machine GM2000

  • Small and lightweight, portable and durable, reliable and economical.
  • Good performance with automactic compensation for voltage fluctuation.
  • Stable arc, deep molten pool, perfect welding shaping.
  • Low consumption with low open energy wastage.
  • Suitable for welding stainless steel, carbon steel and other metal.
  • Voltage Reduction Device (VRD) safety feature included as standard.

Product Description


Specification UNIT GM-2000
Input Voltage VAC 220, 1Ø, 50/60Hz
Rated Voltage % ±15
Rated Input Current AAC 24
Rated Input Power KVA/KW 5.3/4.9
Output Current ADC 20-160
Rated Duty Cycle % 60
Open Circuit Voltage VDC 80
Output Voltage VDC 26.4
Efficiency % 85
Power Factor Ø 0.93
Isolation Class Level F
IP Rating Level IP21S
Dimension (W*D*H) mm 175*380*300
Weight KG 7.0


Specification UNIT GM-2000
Input Voltage VAC 220, 1Ø, 50/60Hz
Rated Voltage % ±15
Rated Input Current AAC 24
Rated Input Power KVA/KW 5.3/4.9
Output Current ADC 20-160
Rated Duty Cycle % 60
Open Circuit Voltage VDC 80
Output Voltage VDC 26.4
Efficiency % 85
Power Factor Ø 0.93
Isolation Class Level F
IP Rating Level IP21S
Dimension (W*D*H) mm 175*380*300
Weight KG 7.0
