MIG/MAG Welder IM5000EF

MIG/MAG Welder IM5000EF

  • Mix gas ready.
  • Precise wire feed speed.
  • Thermostatic control protection.
  • Max cooling efficiency.
  • Proven IGBT design.
  • Increase weldability

Product Description


Specification UNIT IM5000EF
Input Voltage VAC 415, 3Ø, 50/60Hz
Rated Voltage % ±15
Rated Input KVA/KW 29.4/21.5
Output Current ADC 50-500
Output Voltage VDC 16.5-39
Open Circuit Voltage V 70
Duty Cycle at 10min/40°C % 70
Max Output Current ADC 500
Wire Diameter Ø 0.8/1.0/1.2/1.6
Pre-Flow Time Sec 0.5
Post-Flow Time Sec 7
Min Material Thickness mm 0.8<
Insulation Class Level H
IP Rating Level IP21S
Dimension (W*D*H) mm 420*650*580
Weight Kg 70

Specifications Unit Wire Feeder
Input Voltage VDC 24
Wire Size Range MM 0.8-1.6
Wire Feed Speed M/min 1.5-18
Dimension (W*D*H) mm 205*480*300
Weight KG 15.8


Specification UNIT IM5000EF
Input Voltage VAC 415, 3Ø, 50/60Hz
Rated Voltage % ±15
Rated Input KVA/KW 29.4/21.5
Output Current ADC 50-500
Output Voltage VDC 16.5-39
Open Circuit Voltage V 70
Duty Cycle at 10min/40°C % 70
Max Output Current ADC 500
Wire Diameter Ø 0.8/1.0/1.2/1.6
Pre-Flow Time Sec 0.5
Post-Flow Time Sec 7
Min Material Thickness mm 0.8<
Insulation Class Level H
IP Rating Level IP21S
Dimension (W*D*H) mm 420*650*580
Weight Kg 70

Specifications Unit Wire Feeder
Input Voltage VDC 24
Wire Size Range MM 0.8-1.6
Wire Feed Speed M/min 1.5-18
Dimension (W*D*H) mm 205*480*300
Weight KG 15.8
