Stick Welding Machine ST-162

Stick Welding Machine ST-162

  • Portable.
  • Thermostatic control protection.
  • Max cooling efficiency.
  • Proven IGBT design.
  • Increase weldability

Product Description


Specification UNIT ST-162
Rated Input Voltage VAC 220, 1Ø, 50/60Hz
Rated Voltage % ±15
Rated Input Power KVA/KW 7.6/5
Rated Output Current ADC 20-160
Rated Output Voltage VDC 20.4-26.5
Rated Duty Cycle % 100 at 40 °C/10min
Open Circuit Voltage VDC 125
Efficiency % 85
Power Factor Ø 0.67
Isolation Class Level H
Degree of Protection Level IP21S
Dimension (W*D*H) mm 211*400*240
Weight KG 13


Specification UNIT ST-162
Rated Input Voltage VAC 220, 1Ø, 50/60Hz
Rated Voltage % ±15
Rated Input Power KVA/KW 7.6/5
Rated Output Current ADC 20-160
Rated Output Voltage VDC 20.4-26.5
Rated Duty Cycle % 100 at 40 °C/10min
Open Circuit Voltage VDC 125
Efficiency % 85
Power Factor Ø 0.67
Isolation Class Level H
Degree of Protection Level IP21S
Dimension (W*D*H) mm 211*400*240
Weight KG 13


Frequently Purchase Together

YAWATA Welding Electrode 6013, 7018 and others
YAWATA Welding Electrode 6013, 7018 and others
  • Approvals: ABS, BV, DNV, GL, LR, TIS
  • Classification: AWS A 5.1 : E6013 , JIS Z 3211 : E4313
  • Applications: Welding of mild steel sheets for ships, rolling-stocks, structures, and finished welding of heavy structural works
Inverter Welding Machine GM2200
Inverter Welding Machine GM2200
  • Small and lightweight, portable and durable, reliable and economical.
  • Good performance with automactic compensation for voltage fluctuation.
  • Stable arc, deep molten pool, perfect welding shaping.
  • Low consumption with low open energy wastage.
  • Suitable for welding stainless steel, carbon steel and other metal.
  • Voltage Reduction Device (VRD) safety feature included as standard.
MB15 Gas Nozzle
MB15 Gas Nozzle
  • Made of a heat-resistant material, such as brass or copper.
  • Inner diameter : 12mm.
  • Lenght : 54mm.
  • Conical shape.
PICASAFE 13” Full Leather Welding Glove(Red)
PICASAFE 13” Full Leather Welding Glove(Red)
  • Size : 13 inch
  • Red color
  • Thick cow skin leather materials
  • welding gloves, long length
  • Resistance to heat, cold, cut and scratches
  • Good grip in heavy duty work
  • Strong abrasion performance
  • Widely used in construction ,maintenance, agriculture and many other general heavy-duty industry
Oxygen / Acetylene Regulator
Oxygen / Acetylene Regulator
  • Body is machined from class "A" brass bar stock.
  • Self re-seating external safety pressure relief valve on oxygen.
  • Sintered bronze inlet filter.
  • Stem type seat assembly for more reliable performance.
  • 2 gauges for easy reading.
High Pressure Nitrogen Piston Regulator
High Pressure Nitrogen Piston Regulator
  • High Pressure Nitrogen Piston Regulators feature a reliable piston design for precise gas control at high inlet and delivery pressures rating up to 4000 PSIG.
  • Piston type construction.
  • Body and housing cap are machined from class "A" brass.
  • Deirin cap bushing for smooth adjustments.
  • Sintered bronze inlet filter.
  • 2 - 1/2" gauges for easy reading.
  • Regulators verified by ECM, European standard EN ISO 2503:2009 and related to CE Directive 2014/68/EU (Pressure Equipment).
